K Type Aluminium Alloy Pneumatic Ball Vibrators For Pneumatic Vibrating System

China K Type Aluminium Alloy Pneumatic Ball Vibrators For Pneumatic Vibrating System supplier
K Type Aluminium Alloy Pneumatic Ball Vibrators For Pneumatic Vibrating System supplier K Type Aluminium Alloy Pneumatic Ball Vibrators For Pneumatic Vibrating System supplier K Type Aluminium Alloy Pneumatic Ball Vibrators For Pneumatic Vibrating System supplier

Large Image :  K Type Aluminium Alloy Pneumatic Ball Vibrators For Pneumatic Vibrating System

Product Details:

Place of Origin: Ningbo,China
Brand Name: PRIUS,XINYI or OEM
Model Number: K

Payment & Shipping Terms:

Minimum Order Quantity: 5pcs
Price: negotiation
Packaging Details: bag+box+catons+pallet
Delivery Time: 10~15 working days
Payment Terms: T/T, L/C, Western Union,Paypal
Supply Ability: 10000pcs per month
Contact Now
Detailed Product Description
Material: Stainless Steel, Extruded Aluminium Alloy Centrifugal Force: 2910N
Frequence: 46000cycles/Minute At 6 Bar Noise: 60~75Db
Name: Gear Vibrator Port Size: 1/8"



K Type Aluminium Alloy Ball Vibrator for Pneumatic Vibrating System







K-8 pneumatic turbine vibrator with body material aluminum alloy, inlet and exhuasting port size 1/8”G or NPT,working frequency 46000cycles/Minute at 6Bar,centrifugal force 2910N at 6Ba



Quick Detail:



* K-8 Pneumatic turbine vibrator

* Body material Extruded Aluminium Alloy

* Body material stainless steel available

* Inlet and exhuasting port size 1/8”G,NPT

* Working frequence and centrifugal force can be adjustable by air pressure

* High frequence up to 46000cycles/Minute at 6 Bar

* Centrifugal force up to 2910N

* Low noise 60~75Dba

* High temperature-resistance up to 120℃

* Immediately start,stop,fast response

* Easy to operate,safety application

* Easy to change bearing parts

* Lubrication free



Applications:



K-8 Pneumatic turbine vibrator used widely in feed material conveyor,vibration screening,vibrating hopper,packaging filling,foundry sand mold vibration etc











K Type Aluminium Alloy Pneumatic Ball Vibrators For Pneumatic Vibrating System1, Extruded Aluminium Alloy Body
2, Hard Coated Aluminium Turbine Wheel
3-4, High Density Mass Positive Movement
5-7, Cavities Giving Negative Movement
8,Air Inlet Port
9,Air Exhausting port
10,Base Mounting Holes
11,Special Pre-Lubricated Matching Sealed Bearings
Hard Coated Aluminium Endplates
12,With Left direction Thread
13,With Right direction Thread

K Type Aluminium Alloy Pneumatic Ball Vibrators For Pneumatic Vibrating SystemK Type Aluminium Alloy Pneumatic Ball Vibrators For Pneumatic Vibrating System
