PH - G Outer Hexagon One Touch Male Conntector G Thread , Plastic Fitting

50pcs
MOQ
negotiation
Price
PH - G Outer Hexagon One Touch Male Conntector G Thread , Plastic Fitting
Features Gallery Product Description Request A Quote
Features
Specifications
Material: Brass Nickel Plate+Plastic
Working Medium: Air,Vacuum
Colour: Black/White
Pressure: 0~10.20Kgf/cm²
Temperature Range: 0-60℃
Max Pressure: 10.20Kgf/cm²
Tube Material: Pu,nylon,polyurethane
Name: Pneumatic Air Fitting
Port Size: M5~1/2"
Thread: G/NPT/R
Highlight:

Pneumatic Air Fittings

,

Plastic Air Fittings

Basic Infomation
Place of Origin: Ningbo,China
Brand Name: PRIUS,XINYI or OEM
Model Number: PH-G
Payment & Shipping Terms
Packaging Details: bag+box+catons+pallet
Delivery Time: 10~15 working days
Payment Terms: T/T, L/C, Western Union,Paypal
Supply Ability: 200000pcs per month
Product Description

PH - G outer hexagon one touch Male conntector G thread , Plastic Fitting







One touch quick push-in fitting straight,elbow,tee,branch tee,plug,splicer,triple,banjo,reduction type,flow regulating type,swivel type,stop type,check type,bulkhead type,tube size 4mm~16mm,inch size 5/32”~1/2”,thread 1/8”~1/2” PT,G,NPT,Metric thread,brass nickle plated body material e.g PC8-G02





Quick Detail:





* One touch quick push-in fitting

* Body material brass nickle plated

* Housing material PBT,white colour and black colour selectable

* Lock claw material stainless steel,tight and stable

* Round and oval sleeve for option,colour in black and blue selectable

* Fast installation,easy and flexible connecting,saving space

* Diversfied model satisfy any need of piping work

* PTFE leak proof coated on thread to ensure good sealing peformance

* Threads available in G,PT,NPT,METRIC

* Tube size available metric 4,6,8,10,12,16 inch 5/32,3/16,1/4,5/16,3/8,1/2

* Ttraight,tee,branch tee,run tee,elbow,universal elbow(Banjo),plug,splicer,reduction,flow regulator,swivel type,triple type,thread extended type,bulkhead type,check type,stop type







Product Features



1450746409402711.jpg One-Touch tube fittings are used in pnematics piping.

1450746409402711.jpg The tube fittings come in wide varirty of models to meet all your needs in pneumatics piping.

1450746409402711.jpg Even after installation,in direction of the tube can be changed freely.

1450746409402711.jpg Nickel-plated metal body ensures Anti-Corrosion and Anti-Contarmination.

1450746409402711.jpg All R and NPT threads are Pre-Costed sealant.

1450746409402711.jpg All cyilndrical threads are standard with O-Ring seals



Fluid Type Air, Vacuum
Operating Pressure 0~10.2kgf/cm2(0~1.0MPa)
Negative Pressure -750mmHg(10Torr)
Max. Pressure 15.3kgf/cm2(1.5MPa)
Operating Temperature Range 0~60℃
Tube Material

Nylon and Polyurethane



Tube Outer DIA

  Metric Size Inch Size
Code 4 6 8 10 12 16 5/32 3/16 1/4 5/16 3/8 1/2
Dia. Φ4 Φ6 Φ8 Φ10 Φ12 Φ16 Φ5/32 Φ3/16 Φ1/4 Φ5/16 Φ3/8 Φ1/2



Thread Type & Size

Code M5 M6 M8 M10 M12 M12A M14 M16 M20
Dia. 4mm 6mm 8mm 10mm 12mm 14mm 16mm 1/8inch 5/32inch



  55º Taper Pipe Thread (PT) G - Thread
Code 1 2 3 4 6 G01 G02 G03 G04 G06
Dia. R1/8 R1/4 R3/8 R1/2 R3/4 R1/8 R1/4 R3/8 R1/2 R3/4



  UNF NPT1/8
Code U10 N01 N02 N03 N04 N06
Size 10-32UNF NPT1/8 NPT1/4 NPT3/8 NPT1/2 NPT3/4



PH - G Outer Hexagon One Touch Male Conntector G Thread , Plastic Fitting 6

PH - G Outer Hexagon One Touch Male Conntector G Thread , Plastic Fitting 7



PH - G Outer Hexagon One Touch Male Conntector G Thread , Plastic Fitting 8



PH - G Outer Hexagon One Touch Male Conntector G Thread , Plastic Fitting 9
